Revolution CIMple Box Mount Assembled
A Revolution module with integrated transmission and two CIM motors.

Features high-quality Andymark Inc. components and is based on their CIMple Box single speed gearbox.

The final drive ratio is approximately 10.35:1 from the CIM shaft to the wheel output. This generate about 450 RPM of wheel speed or a ground speed of about 7.4 Ft/sec.

This mounting plate is specially designed to work with the C-Base Chassis System.

Combine this module with our PG71 Steering Mount to build a complete swerve/crab mobile robot.

Weight shown with Revolution module and two CIM motors.

This module comes completely assembled with Revolution and CIM motors!

Choose your module color and wheel style before ordering below.

The STEP models currently available use the older style of Revolution module. The new module is shorter and uses a smaller wheel.

Weight: 9.6 lbs.

Files


$495.00
Custom Order Only
